General Information
Cable Trays General Information
EAE cable trays and ladders provide high-strength cable protection that protects the cables from external factors. EAE cable trays are mass produced with the 'Roll Forming' method on automatic production lines. The standard tray length is 3m. 6m can be produced upon request.
Cable tray supports and protects power cables, communication cables and wires, and helps to expand, make stable and restructure the cable network.
Products
Types of Cable Tray
EAE cable tray types are mass produced with the "Roll Forming" method and product types that will meet all your needs. Cable tray selection is made in compliance with the number, diameter, weight of the cables that will pass through the duct and the environment it is to be utilized in.
E-Line A-A: Cable Support Systems and Accessories
The Suspension-Accessory System E-Line AA; designed to carry busbars, cable trays, and cable ladders, etc. on reinforced concrete or steel structures. EAE Suspension Systems can be produced in pre-galvanized, hot-dip galvanized, and painted types with thicknesses ranging from 2mm to 6mm depending on the coating type. Special suspension systems and shaft hangers can also be designed to provide solutions according to the needs of the construction sites.
Types of Cable Tray
Types of Cable Tray According to Coating Type
Galvanized Cable Tray
If a sheet metal cable tray is coated with Zinc (Zn), it is called a galvanized cable tray. Due to the nature of the metal used in sheet materials, it tends to interact with oxygen. As a result of this action, a copper-colored brownish surface damage begins to occur on the surface of the material, which we call corrosion.
Over time, this corrosion deforms the structure of the sheet material and causes it to scatter easily. To prevent this corrosion, its surface must be covered with a material that will prevent its contact with oxygen. Zinc (Zn) is the most preferred coating material in the industry due to its economic specifications. The process of coating with zinc is called galvanizing.
- Pre-galvanized Coating
- Hot-Dip Coating
- Electro Galvanized Coating
Types of Cable Tray
Types of Cable Tray According to Material Type
Stainless steel cable trays are manufactured from high-quality stainless steel materials of grade 316L or 304. Grade 316L stainless steel is especially preferred in marine and industrial environments. It belongs to the austenitic class of stainless steels containing molybdenum and offers high anti-corrosive and mechanical properties. It is particularly suitable for welding and forming processes.
It is ideal for use in marine environments, as well as in oil and chemical facilities. Another high-quality stainless steel variant, AISI 304 grade, is suitable for façade applications, industrial facilities, and similar environments. AISI 304 (1.4301) grade stainless steel is commonly used in factories, façades, and other areas exposed to corrosion, due to its strong anti-corrosive characteristics. In cases where it is not necessary, stainless steel surfaces do not require any additional coating. Both AISI 304 and 316L grades are ideal materials for highly corrosive environments.
Types of Cable Tray
Cable Tray Types According to Design Type
It is the name given due to the shape formed, because of forming the edge parts during the production of cable trays. Since the thickness of the cable tray is thin, the edges are extremely suitable for cutting cables. To prevent this, it is very important to use a curved form.
